Schedule 40 BE

Schedule 40 BE
Schedule 40 BE

Schedule 40 BE

PVC Plastic Pipe Schedule 40

SCH 40 BE PVC 1120

Schedule 40 BE PVC 1120

POLYVINYL CHLORIDE     TYPE 1, GRADE 1     20 FOOT LENGTHS

Nominal Size

Outside Diameter

Wall Thickness

Weight Per 100 Foot

Pressure rating@73.4°

Foot Per Bundle

.5″

.840

.109

16.20

600

200

.75″

1.050

.113

21.50

480

200

1″

1.315

.133

31.70

450

200

1.25″

1.660

.140

42.90

370

1.5″

1.900

.145

51.20

330

2″

2.375

.154

68.70

280

2.5″

2.875

.203

108.60

300

3″

3.500

.216

142.20

260

4″

4.500

.237

202.50

220

6″

6.625

.280

356.60

180

8″

8.625

.322

572.40

160

10″

10.750

.365

760.80

140

12″

12.750

.406

1006.10

130

PipeLife Jet Stream, Inc. DWV meets the requirements of FHA use of Materials Bulletin UM53.
Meets the requirements of NSF and carries its Seal of Approval.
BOCA Southern Building Code Congress, and many other state, local, federal and military codes.

USE ONLY PVC CEMENT
Conforms to Commercial Standard CS 272-65
